Page 13 - KING TONY Roca

Impact Torsion Bit ▪ Silicon chrome vanadium alloy steel(S2)
▪ Anti-rust oiled, electroplating

7T50P 7T50Z
▪ Short neck (9.5 mm) type ▪ DIN ISO 2351-2
▪ DIN ISO 2351-2
Overall length Overall length g
KT NO. g set KT NO. No. (mm) set
No. (mm)
7T5001P-S1 PH1 50 18 7T5001Z-S1 PZ1 50 18
7T5002P-S1 PH2 50 18 20 / 160 7T5002Z-S1 PZ2 50 18 20 / 160
7T5003P-S1 PH3 50 20 7T5003Z-S1 PZ3 50 20
7T50S 7T50H

▪ DIN ISO 2351-1 ▪ DIN ISO 2351-3

Tip Tip Overall
KT NO. width thickness length g set KT NO. Overall length g set
(mm) (mm) (mm) mm (mm)
7T5003S-S1 3.0 0.5 50 16 7T5003H-S1 H3 50 18
7T5004S-S1 4.0 0.5 50 16 20 / 160 7T5004H-S1 H4 50 18 20 / 160
7T5005S-S1 5.0 0.8 50 20 7T5005H-S1 H5 50 22
7T5006S-S1 6.0 1.0 50 20 7T5006H-S1 H6 50 24
7T50T

▪ For torx head screw 30x
Service life
KT NO. Size Overall length g set Torsion zone
(mm)
7T5010T-S1 T10 50 16 ▪ Absorbs high impact stress
7T5015T-S1 T15 50 16 ▪ Enhance the torsion effect
7T5020T-S1 T20 50 18 ▪ Reducing Bit breakage
7T5025T-S1 T25 50 18 20 / 160 ▪ Achieve up to a 30X increase
7T5027T-S1 T27 50 20 in lifespan
7T5030T-S1 T30 50 20
7T5040T-S1 T40 50 22

Compact Magnetizer / Demagnetizer

76MBH 1 PC. 76MBH-S2 2 PC.

• Use to catch the screw with a strong magnet power
• Hold screwdriver bit 4 ~ 6.35mm round or hex shank
• Mini length 24mmL
• Function as magnetizer / demagnetizer / storage
• Demagnetize by slide outer shallow groove
• X30 powerful magnet compare to wearing magnet tip

76MBH
KT NO. PC Size(mm) g
76MBH 1 24 x 14 x 13 25 12 / 144
76MBH-S2 2 24 x 14 x 13 50 60 / 360
Functions Combined

76MBH-S2
• Fast demagnetize: Side groove • Fast magnetize:Put in • Suitable for various tool • Easy storage:
to demagnetize the tools to magnetize the tools combinations, such as • The magnetic attraction feature allows the screwdriver
screwdrivers, hex wrenches, to be stored on a metal surface, effortlessly solving
power Bits, and more the screwdriver storage issue

12
